Construction, EX-Line Dust Extractors, Industry, Mobile Dust Extractors, Pneumatic Dust Extractors

DC 5900 TR

Air driven dust extractor for heavier applications – no electrical power required

ejector is maintance free
low weight
no electrical power required
high reliability in operation
easy service

Select model

The DC 5900 TR is a machine driven by compressed air for use in areas where electricity is not available or not permitted. The DC 5900 TR has a very robust design and extra high extraction power, which makes it ideal for source extraction on bigger machinery and in mines. It is also ideal for source extraction from most types of handheld power tools.

Supplied with:

Plastic bags, 5 pcs (46145)
Fine filter, polyester (429204)
HEPA H13 filter (42869)

DC 5900 TR can be ordered with antistatic accessories to fulfill the requirements of the ATEX Zone 22 directive 1999/92 ATEX 137.

HxWxD [in]	71x30x39
Weight [lb]	330
Inlet Ø [in]	3
Hose length Ø50mm/2'' [m/ft]	5-15/16-49
Collecting container [l/gal]	60/15.5
Max. flow fan (US/CAN) [CFM/m3/h]	300/500
Negative pressure max. (US/CAN) [inwg/kPa]	84/21
Grounding	Connection via compressed air hose.
Compressed air consumption [m3/min at 6 bar]	21
Connection dimension [in]	R 1
Rec. quick coupling for pneumatic hose [in]	1
Fine filter polyester, area [ft2]	16.4
Degree of separation fine filter, EN 60335-2-69, Class M [%]	99.9
HEPA filter, area [ft2]	8.2
Filter classification HEPA filter, EN 1822-1	HEPA H13
Degree of separation machine, EN 60335-2-69, Appendix A-A, Class H [%]	99.995
Max. sound level [dB(A)]	>75
