Y-Pipe (Reinforced Spiro Tubing)

The reinforced spiro tubing system is used to connect the separator and vacuum pump. It is also used in extraction systems for smoke and light dust.

Select model
  • Model Part no
    Request
  • Ø125 3127
    Request
  • Ø160 3128
    Request
  • Ø200 3129
    Request
  • Ø250 3130
    Request

Spiro tubing is used most commonly for the connection of the central unit components, vacuum producer, filter unit and pre-separator. Spiro is not generally suitable for application with coarse and abrasive material but is commonly used in extraction systems for vapour, fume and light dust.

Note: The letters in the table header refer to the drawing.

Y-pipe
Part No Description d [mm] r [mm] l [mm] M [mm] Weight [kg]
3127 Ø125 125 190 375 190 1.5
3128 Ø160 160 240 480 240 2.5
3129 Ø200 200 300 600 300 3.8
3130 Ø250 250 375 750 375 8.6



For more detailed information, please read our
